Keycloak Integration in Minutes with Cloud IAM and WunderGraph

Stefan Avram

Stefan Avram

min read

We're hiring!

We're looking for Golang (Go) Developers, DevOps Engineers and Solution Architects who want to help us shape the future of Microservices, distributed systems, and APIs.

By working at WunderGraph, you'll have the opportunity to build the next generation of API and Microservices infrastructure. Our customer base ranges from small startups to well-known enterprises, allowing you to not just have an impact at scale, but also to build a network of industry professionals.

We are very excited to announce our most recent partnership with Cloud IAM - the Keycloak Identity and Access Management as a Service solution used by 10,000+ developers. Cloud IAM offers a fully managed Keycloak that is white-labeled, GDPR compliant, secure, cloud agnostic and scalable.

For many developers, Keycloak is the preferred software for IAM. However, integrating and using it for your application is time-consuming, since you need to monitor, secure, scale, update and back it up.

By using the integration for WunderGraph and Cloud IAM , you can build Keycloak authentication into your application with ease. Cloud IAM automates the setup, running, and scaling of Keycloak clusters. WunderGraph lets you integrate authentication with your frontend and backend in minutes. WunderGraph’s unified Virtual Graph automates 90% of integration tasks and provides an unparalleled developer experience, authentication-aware data fetching and much more out of the box. Bring everything together and reach lightspeed levels of development! This demo was done using our quick start chat application. You can use this link to clone the repo and follow along with this demo to integrate cloud IAM in under 10 minutes.

How it works

If you want to use Keycloak for your next project with WunderGraph, here is how you can get started. First, you need to set up your Cloud IAM. You can start with the free Little Lemur plan. Once you have created an account. Create a new deployment on the deployment page.

Cloud IAM New deployment

Once a new deployment has been created. You will be given admin credentials to access your deployment. Save these credentials and then select Keycloak Console and proceed to your deployment.

Once you are inside the deployment. You should see something like this. Head over to the Clients tab and add your WunderGraph Client.

Cloud IAM client navigation
Cloud IAM client setup

When you are adding your WunderGraph Client, you need to configure your settings shown in the example below. Change the Access Type to Confidential and give a valid redirect URI. We just used our local host as the redirect URI. It’s important to change the Access Type to Confidential because this will generate an OpenID Connect Confidential client that is on the backend and not on the frontend. Make sure to click save at the bottom.

Cloud IAM access type

Now if you check the Credentials tab you will see a secret. Now you can head back to Realm Settings tab and you should see a link Endpoint at the bottom labeled Open ID Endpoint Configuration. Click it and you will be redirected to a page with a big json blob. For now, take note of the URL. It should look like this


You’ll need everything before /.well-know. So copy it and paste it in a safe place for later use.


After that, you declare Cloud IAM as your login provider to authenticate users. You can do this by heading over to the wundergraph.config.ts file and adding the following:

  • Your ID is whatever you want to call it.
  • Your clientID is the name of the client you made earlier in IAM.
  • Your secret can be found under the client credentials tab. Make sure to hide it better than I did.
  • Your issuer is that link from the Open ID Endpoint Configuration link. Please paste it in the issuer.

The client is then generated by WunderGraph and is aware of Cloud IAM as the authentication provider and of Keycloak as the method used. It provides all the user information provided by Cloud IAM and lets you log in and log out users with a single function call.

If you look inside the Web Client, you should see that WunderGraph picked up on the changes and configured Cloud-IAM for us automatically.

Generated Auth Client

Now everything is configured, the login flow will look like this: A user logs into the web application and is redirected to the WunderGraph Server (WunderNode) . From there, the user is redirected to Cloud IAM for authentication, and then redirected back when the login is successfully completed. Every step of the process is automated, giving you one less thing to worry about.

If you want to learn more about how WunderGraph handles authentication, check out our detailed documentation .

Time to start your first project!

You can start using Keycloak with Cloud IAM and WunderGraph today! We would love to see what you have built and what other integrations you would like to see. We are looking forward to welcoming you on our Community Discord Channel soon!

If you want to take your WunderGraph application to the next level with dedicated support from our team, use this link to schedule a meeting with us.

Live Demo
